Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
|Cable length||3.6 m|
|Colour of product||Beige|
|Dimensions (WxDxH)||44 x 44 x 610 mm|
|Input frequency||50/60 Hz|
|Load capacity||1800 VA|
|Nominal input voltage||120 V|
|Operating relative humidity range||0 - 95 %|
|Operating temperature range (T-T)||0 - 45 °C|
|Output connections||14 x NEMA 5-15R|
|Package dimensions (WxDxH)||178 x 152 x 648 mm|
|Storage relative humidity range||0 - 95 %|
|Storage temperature range (T-T)||-25 - 65 °C|
