HP 3800-48G-4XG
The HP 3800 Switch Series is a family of fully managed Gigabit Ethernet switches. There are a total of nine switch models—a 24-port switch, a 48-port switch, a 24-port PoE+ switch, a 48-port PoE+ switch

with either SFP+ or 10GBASE-T uplinks, and a 24-portSFP switch with 2 SFP+ uplinks. HP 3800 Series Switches utilize the latest HP ProVision ASIC technology and combine the latest advances in hardware engineering to deliver one of the most resilient and energy-efficient switches in the industry.

The 3800 series implements meshed stacking technology to deliver chassis-like resiliency in a flexible stackable form factor.
Authentication methodIEEE 802.1X, RADIUS, MAC
Auto MDI/MDI-XYes
Basic switching RJ-45 Ethernet ports quantity52
Built-in processorHP ProVision ASIC/ARM 350 Mhz & Freescale PowerPC 1200 MHz
CertificationFCC Class A, VCCI Class A, EN 55022/CISPR 22 Class A EN 55024, CISPR 24, EN 55024, CISPR 24, IEC 61000-4-2/3/4/5/6/8/11, IEC 61000-3-2/3, EN 61000-3-2/3 80 PLUS GOLD
Colour of productGrey
Connectivity technologyWired
Copper ethernet cabling technology1000BASE-T,100BASE-TX,10BASE-T,10GBASE-T
DHCP clientYes
DHCP serverYes
DiagnosticsLLDP
Dimensions (WxDxH)467.4 x 442.7 x 43.2 mm
Drive device, buffer size36 MB
Firmware upgradeableYes
Flash memory4096 MB
Form factor19"
Full duplexYes
Gigabit Ethernet (copper) ports quantity48
Heat dissipation635 BTU/h
Input current6 - 3 A
Input frequency50 - 60 Hz
Input voltage100 - 240 V
Installed ports52
Internal memory2048 MB
Latency1.9µs
MAC address table65500 entries
Management platformSNMP, Telnet, Web
Management protocolsSNMP v3
Maximum data transfer rate10000 Gbit/s
Memory typeSDRAM
MIB supportYes
Mounting1U
Networking featuresGigabit Ethernet, 10G Ethernet
Networking standardsIEEE 802.1ab,IEEE 802.1D,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u
Noise level34 dB
Number of power supply units1
Number of VLANs2048
Operating altitude0 - 3000 m
Operating relative humidity (H-H)15 - 95 %
Operating relative humidity range15 - 95 %
Operating temperature (T-T)0 - 55 °C
Operating temperature range (T-T)0 - 55 °C
Packet buffer memory36 MB
Ports quantity52
Power consumption (typical)186 W
Power over Ethernet (PoE)No
Power over Ethernet (PoE) supportNo
Power supply400 W
Power supply typeHP X311
Quality of Service (QoS) supportYes
Rack mountingYes
Redundant power supply (RPS) supportYes
SafetyEN 60950/IEC 60950, UL 60950, CAN/CSA 22.2 No. 60950, EN 60825
Security algorithms802.1x RADIUS,SSH,SSL/TLS
Security algorithms supported802.1x RADIUS, SSH, SSL/TLS
Security featuresCLI, GUI, MIB
Source data-sheetIcecat.biz
Spanning tree protocolYes
StackableYes
Storage relative humidity (H-H)15 - 90 %
Storage temperature (T-T)-40 - 70 °C
Storage temperature range (T-T)-40 - 70 °C
Supported data transfer rates10/100/1000 Mbps
Switch layerL3
Switch typeManaged
Switching capacity176 Gbit/s
Throughput130900000 pps Mpps
Web-based managementYes
Weight7420 g
Wi-FiNo
Wireless LAN connectionNo

Similar products

  • TP-LINK 8-port 10/100 Unmanaged PoE Switch
    TP-LINK 8-port 10/100 Unmanaged PoE Switch
  • TP-LINK TL-SF1005D
    TP-LINK TL-SF1005D
  • TP-LINK 8-Port 10/100Mbps Desktop Switch
    TP-LINK 8-Port 10/100Mbps Desktop Switch
  • TP-LINK TL-SG1008
    TP-LINK TL-SG1008
  • TP-LINK TL-SM311LS
    TP-LINK TL-SM311LS

Hewlett Packard Enterprise 3800-48G-4XG

Managed, 48 x RJ-45 10/100/1000 Mbps, 4 x RJ-45 10-GbE, 1 x RJ-45 Console, HP ProVision ASIC/ARM 350 MHz, Freescale PowerPC 1200 MHz, 4GB Flash, Buffer 36 MB, 2GB SDRAM, RADIUS/TACACS+, SSHv2, SSL, 48.26 cm (19 ") , 186W, 7.42kg

J9586A

Stock Due 01-02-2024

£9,372.62
£7,810.51 Ex VAT.
