ETGEAR BR500-100UKS
  • ETGEAR BR500-100UKS
Reasons to Buy
  • One-step Instant VPN for business protection and remote or site-to-site secure access
  • Easy setup, configuration and instant VPN connectivity from the NETGEAR Insight app or Cloud Portal
  • Stateful Packet Inspection Firewall and easy rule setting for instant protection against intrusion
  • Router setup (DHCP, NAT rules, DMZ ports) from the Insight app or Cloud Portal
  • Full routing capabilities with DHCP, NAT, PPTP, L2TP
  • VPN Business Router with InterVLAN routing, Support for QoS and 802.1q VLANs (256)
  • VLAN in VLAN support (QinQ) for private VLAN tagging in ISP network for an additional layer of isolation and security
  • VPN with SSL Encryption (DES, 3DES, AES)


Technical Headlines
  • Ethernet WAN SFP WAN
  • IEEE 802.1Q
  • Gigabit Ethernet
  • Web-based management
  • DHCP server
  • 3DES, 128-bit AES, 256-bit AES, AES, DES, MD5, RSA, SHA-1, SSL/TLS


Insight Instant VPN Router
The NETGEAR® Insight™ Instant VPN Router, a business-class router with Instant VPN technology, is not only a high performance router for small to medium-size businesses, but also offers a Stateful Packet Inspection (SPI) firewall. Additionally, state-of-the-art Instant Virtual Private Network (VPN) technology provides remote access and office-to-office connectivity with simple configuration.

Configure and setup remote connections to your office, or even better connect to up to three locations using the Instant VPN router – just a few taps away from your phone or from the web portal of the Insight manager. The VPN connections are encrypted to offer a secure link between your laptop and your office whether you’re on the road, at a coffee shop, or in another country. The same is true for site-to-site connections, when you decide to connect your home, office, or several other locations that need to be interconnected.

NETGEAR Insight offers visibility and access to all features from routing to VPN. Setup, configure, manage and monitor all from a single pane of glass.
Authentication method NETGEAR Insight SSO
Built-in processor Yes
Cables included LAN (RJ-45)
Cabling technology 10/100/1000Base-T(X)
Certification FCC 15 B, CE, C-Tick B, VCCI
Depth 187.5 mm
DHCP server Yes
DMZ support Yes
Ethernet interface type Gigabit Ethernet
Ethernet LAN (RJ-45) ports 4
Ethernet LAN data rates 10,100,1000 Mbit/s
Firewall Yes
Firewall security Stateful packet inspection (SPI) firewall
Flash memory 128 MB
Height 43.6 mm
Internal memory 1024 MB
LED indicators Yes
Linux operating systems supported Yes
Mac operating systems supported Yes
Manual Yes
Networking standards IEEE 802.1Q
Operating relative humidity (H-H) 0 - 90%
Operating temperature (T-T) 0 - 45 °C
Output voltage 12 V
Quality of Service (QoS) support Yes
Quick installation guide Yes
Quick start guide Yes
Routing protocols RIP-1, RIP-2
Safety CE/LVD, cUL
Security algorithms 3DES, 128-bit AES, 256-bit AES, AES, DES, MD5, RSA, SHA-1, SSL/TLS
Source data-sheet Icecat.biz
Storage relative humidity (H-H) 0 - 95%
Storage temperature (T-T) -20 - 70 °C
Supported network protocols IPv6
Throughput 0.924 Gbit/s
Universal Plug and Play (UPnP) Yes
URL filtering Yes
VPN tunnels quantity 3
Web-based management Yes
Weight 1.55 kg
Width 314 mm
Windows operating systems supported Yes
Ethernet WAN Yes
DSL WAN No
SIM card slot No
3G/4G USB modem compatibility No
Sustainability compliance Yes
Compliance certificates CE, Low Voltage Directive (LVD), RoHS
SFP WAN Yes

Specific References

EAN13
0606449135961

BR500-100UKS.pdf

NETGEAR BR500-100UKS Data Sheet

NETGEAR BR500-100UKS

NETGEAR BR500-100UKS, Ethernet WAN, Gigabit Ethernet, White
Out of Stock
£178.86
£178.86 Ex. VAT
Reference: BR500-100UKS
