Auto MDI/MDI-X | Yes |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Certification | CE; FCC; RoHS |
Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Depth | 64 mm |
Flow control support | Yes |
Form factor | Desktop |
Heat dissipation | 12.11 BTU/h |
Height | 24 mm |
Housing material | Metal |
Input current | 1 A |
LED indicators | Activity, Link, Power |
MAC address table | 2000 entries |
Mean time between failures (MTBF) | 1455562 h |
Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Power source | DC |
Quality of Service (QoS) support | Yes |
Source data-sheet | Icecat.biz |
Stackable | Yes |
Storage relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -10 - 70 °C |
Store-and-forward | Yes |
Switch type | Unmanaged |
Switching capacity | 10 Gbit/s |
Weight | 160 g |
Width | 100 mm |
Harmonized System (HS) code | 85176990 |
Compliance certificates | CE, RoHS |
