10G support | No |
Auto MDI/MDI-X | Yes |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Copper ethernet cabling technology | 100BASE-TX, 10BASE-T |
Data transfer rate | 200 Mbit/s |
Depth | 102 mm |
Flow control support | Yes |
Full duplex | Yes |
Heat dissipation | 9.548 BTU/h |
Height | 28 mm |
Housing material | Metal |
Input current | 1 A |
Input voltage | 5 V |
LED indicators | Link, Power |
MAC address filtering | Yes |
MAC address table | 1000 entries |
Maximum data transfer rate | 0.1 Gbit/s |
Mean time between failures (MTBF) | 511.323 h |
Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 50 °C |
Package height | 68 mm |
Package weight | 610 g |
Package width | 208 mm |
Packet buffer memory | 0.768 MB |
Power over Ethernet (PoE) | No |
Power source | DC |
Quality of Service (QoS) support | Yes |
Rack mounting | No |
Source data-sheet | Icecat.biz |
Stackable | No |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -10 - 70 °C |
Store-and-forward | Yes |
Supported data transfer rates | 10/100 Mbps |
Switch type | Unmanaged |
Switching capacity | 1.6 Gbit/s |
Weight | 412 g |
Width | 162 mm |
Half duplex | Yes |
Shipping (inner) case net weight | 6.1 kg |
Shipping (inner) case gross weight | 7 kg |
Pallet gross weight (air) | 357.5 kg |
Pallet height (air) | 2.07 m mm |
Pallet gross weight (sea) | 357.5 kg |
Pallet height (sea) | 2.07 m mm |
Harmonized System (HS) code | 85176990 |
Products per shipping (inner) case | 10 pc(s) |
Master (outer) cases per pallet (air) | 48 pc(s) |
Products per pallet (air) | 480 pc(s) |
Pallet gross length | 102 cm mm |
Pallet gross width | 122 cm mm |
Master (outer) cases per pallet (sea) | 48 pc(s) |
Products per pallet (sea) | 480 pc(s) |
Compliance certificates | C-TICK, CB, CE, Federal Communications Commission (FCC), ICES, RoHS, VCCI, cUL |
