Save time with easy and convenient remote accessibility.
Network manageable via serial, USB or optional Ethernet. Includes Powerchute Network Shutdown Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.
Low operating and maintenance costs with proven reliability and intelligent battery management.
Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.
Avoids costly power problems by keeping your IT equipment and data protected and available.
Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation ,and zero transfer time to battery during power events.
Peace of mind that comes with full equipment compatibility and reliability of a leader
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.
AC outlet types |
C13 coupler,C19 coupler |
AC outlets quantity |
12 AC outlet(s) |
Battery capacity |
367 VAh |
Battery recharge time |
3 h |
Battery technology |
Sealed Lead Acid (VRLA) |
Cable length |
2.44 m |
Certification |
CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE |
Colour of product |
Black |
Crest factor |
3:1 |
Depth |
584 mm |
Display |
LCD |
Energy Star certified |
Yes |
Ethernet LAN (RJ-45) ports |
1 |
Height |
85 mm |
Input operation voltage (max) |
600 V |
Input operation voltage (min) |
96 V |
International Protection (IP) code |
IPX8 |
LED indicators |
Yes |
Noise level |
97.4 dB |
Non-operating altitude |
9144 m |
Operating altitude |
0 - 3000 m |
Operating relative humidity (H-H) |
0 - 95 % |
Operating temperature (T-T) |
8 - 35 °C |
Output operation voltage (max) |
240 V |
Output operation voltage (min) |
220 V |
Output power |
1980 W |
Output voltage |
230 V |
Output voltage THD |
2 % |
Package weight |
34020 g |
Package width |
599 mm |
Power supply input frequency |
40 - 70 Hz |
Replacement battery cartridge |
APCRBC141 |
RoHS compliance |
Yes |
Source data-sheet |
Icecat.biz |
Storage relative humidity (H-H) |
0 - 95 % |
Storage temperature (T-T) |
-20 - 50 °C |
Surge energy rating |
990 J |
USB port |
Yes |
Waveform |
Square |
Weight |
25000 g |
Width |
432 mm |
Specific References
- EAN13
- 0731304327561
