Cable length | 3 m |
Certification | CSA C22.2 No. 60950,IEC 60950,METI Denan,UL 60950-1,VDE RoHS, REACH |
Dimensions (WxDxH) | 56 x 44 x 902 mm |
Input connection type | IEC 309 16A 2P+E |
Input frequency | 50/60 Hz |
Maximum input current per phase | 16 A |
Maximum total current draw per phase | 16 A |
Nominal input voltage | 200 - 230 V |
Nominal output voltage | 230 V |
Operating relative humidity (H-H) | 5 - 95 % |
Operating relative humidity range | 5 - 95 % |
Operating temperature (T-T) | 5 - 45 °C |
Operating temperature range (T-T) | 5 - 45 °C |
Output connections | 18x IEC 320 C13 2x IEC 320 C19 |
Package dimensions (WxDxH) | 162 x 107 x 1124 mm |
Package weight | 4920 g |
Source data-sheet | Icecat.biz |
Storage relative humidity (H-H) | 5 - 95 % |
Storage relative humidity range | 5 - 95 % |
Storage temperature (T-T) | -25 - 65 °C |
Storage temperature range (T-T) | -25 - 65 °C |
Weight | 2930 g |
