Connectivity technology | Wireless |
Depth | 15.7 mm |
Frequency range | 2.4 - 5 GHz |
Height | 7.39 mm |
Host interface | USB |
Interface | WLAN |
Internal | No |
LED indicators | Status |
Mac operating systems supported | Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
Maximum data transfer rate | 1267 Mbit/s |
Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Package height | 30 mm |
Package weight | 10 g |
Package width | 138 mm |
Quick installation guide | Yes |
Security algorithms | WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3, WPA3-SAE |
Source data-sheet | Icecat.biz |
Storage relative humidity (H-H) | 5 - 95% |
USB version | 2.0 |
Wi-Fi | Yes |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Width | 19.9 mm |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
