Connectix Tool-less Keystone Modules ensure a quick and easy to terminate installation. The snap-fit to terminate design means that a punch down tool is not required.

They have been designed to be installed into most UK and European Keystone applications, including standard or angled faceplate products, patch panels or surface boxes.

The loading cap is colour coded to T568B standards to ensure a quick and easy installation. The module offers a high performance transmission that meets or exceeds Category 6 standards.

Features:

• Quick and easy to install
• Snap-fit to terminate
• Suitable for all standard Keystone applications
• Integrated cable tie position
• Category 6 hardware performance
• T568B colour coded wiring terminals

Specification:

• Width - 17.1mm
• Depth - 38.2mm
• Height - 21.3mm
• Mounting Hole Size - 19.3mm x 14.7mm
• Material - Polycarbonate/ABS thermoplastic resin with grade UL94 VO at 1.5mm flame retardency
• IDC Labels - Colour coded to T568B
• IDC Blocks - Tool-less IDC mechanism
• Conforms to - ANSI/TIA-568-C Category 6 Specification
